Blackmagic Design DeckLink Quad HDMI Recorder
DeckLink Quad HDMI Recorder is a high performance PCIe card that lets you capture from 4 different HDMI sources in any combination of SD, HD, Ultra HD, 4K and even computer formats, all at the same time! Featuring 4 independent HDMI 2.0b input connections, DeckLink Quad HDMI is like getting 4 separate and customizable capture cards in one, making it perfect for software live switching, real time computer game capture, streaming and more!
- Record up to DCI 4K60 HDMI Video
- 4 x HDMI 2.0b Inputs
- PCIe Interface Card
- Up to 4K30 12-Bit 4:2:2 in All Modes
- Switchable-Mode HDMI Inputs
- 8-Channel, 24-Bit 48 kHz Embedded Audio
- macOS, Windows, and Linux Compatible
System ConnectionPCIe 1.0 x8 Video Inputs4 x HDMI (HDMI 2.0b) Input Video FormatHDMI (8/10/12-Bit 4:4:4/4:2:2/4:2:0 RGB, YUV)
576i / 625 lines at 50 fps
480i / 525 lines 59.94 fps
720p 50/59.94/60 fps
1080p 23.98/24/25/29.97/30/50/59.94/60 fps
1080i 50/59.94/60 fps
UHD 4K 23.98/24/25/29.97/30/50/59.94/60 fps
DCI 4K 23.98/24/25/29.97/30/50/59.94/60 fps
480p at 60 fps
Simultaneous Multi-Input SupportNot Specified by ManufacturerStandards HDCP SupportNone HDR CompatibilityNot Specified by ManufacturerHardware OS CompatibilityWindows 8.1 or Later
macOS 10.14 or Later
*As of June, 2020: Check with manufacturer for the most up-to-date compatibility
Power Consumption23 WEnvironmental Operating Temperature41 to 104°F / 5 to 40°C Storage Temperature-4 to 113°F / -20 to 45°C Operating Humidity0 to 90%General CertificationsCE, FCC, RCM Dimensions4.29″ / 108.97 mm Weight4.51 oz / 128 gPackaging Info Package Weight0.4 lb Box Dimensions (LxWxH)6 x 5.5 x 1″
3 Year Limited Manufacturer’s Warranty
