Blackmagic Design HyperDeck Studio 4K Pro
The Blackmagic Design HyperDeck Studio 4K Pro is an updated 1 RU file-based deck that features the same functionality and control of professional tape decks in a digital design. This model updates the previous HyperDeck Studio models with several features including 12G-SDI support, two added SD card slots, USB-C recording output, timecode input and output, Ref input and output, a redesigned jog/shuttle wheel, 10G Ethernet, and a speaker on the front.
The Studio 4K Pro records video with 10-bit 4:2:2 color using either ProRes or DNxHD codecs, as well as the H.264 and H.265 compression formats. With two SSD slots and two SD card slots, you can record almost endlessly as one SSD becomes full, recording automatically continues on to the other, and the SD card slots are also hot-swappable. The Studio 4K Pro features one 12G-SDI input, two 12G-SDI outputs, a loop-through 12G-SDI output, a dedicated SDI monitor output, and there’s also one HDMI input and one HDMI output that can all output up to DCI 4K. The 4K Pro can even play ProRes 4444 files in true UHD for fill and key outputs. The ports autodetect the signal and will adjust to the SD, HD, 6G-SDI, or 12G-SDI format input. The 3-pin XLR timecode input and output allow you to sync timecode with other devices, and it also allows you to daisy-chain with other devices to create a timecode sync chain.
The Studio 4K Pro is a 1 RU rack-mountable unit, with built-in rack mount ears. It features illuminated front panel button control and a heavy jog/shuttle wheel for analog scrubbing. RS-422 control is supported for external control using the Ref input and output ports. The USB-C port allows you to record to external disks, and you can also use it to plug into a computer to use as a source for a web stream. An integrated LCD on the front panel allows you to monitor the video and display timecode and transport information.
Professional Broadcast Deck
The new HyperDeck Studio recorders have been totally redesigned with dozens of new features. The advanced models have new broadcast-style front panel controls and more connections on the rear panel. The LCD screen supports both light and dark modes, plus the transport control buttons are stronger with a firm professional feel. The Pro models feature a machined metal search dial with increased mass and a soft rubber surface that feels nice to the touch. Plus the search dial features an active clutch, just like a traditional broadcast dec. With dual media slots, you can change cards without interrupting recording. The advanced models even include a front headphone connection and speaker.
- 1 RU File-Based Video Recorder
- H.264/H.265 10-Bit 4:2:2 Video
- Records Compressed in ProRes / DNxHD
- 1 x 12G-SDI Input, 2 x 12G-SDI Outputs
- 2 x 2.5″ SSD Slots & 2 x SD Card Slots
- 1 x HDMI Input, 1 HDMI Output
- 1 x SDI Loop Output, 1 x USB-C Out
- Speaker, Remote, 10G Ethernet Port
- Front-Panel Buttons, Jog Wheel, LCD
- Timecode, Reference & RS-422 In/Out
Format SupportDCI/UHD 4K 2160p: 30/29.97/25/24/23.98
2K 1440p: 30/29.97/25/24/23.98
480p60 and 576p50 via HDMI Only
Display Size2.2″ LCDInputs / Outputs USB I/O1 x USB-C 3.1/3.2 Gen 2 Female Output Video I/O1 x BNC (12G-SDI) Input
2 x BNC (12G-SDI) Output
2 x BNC (3G-SDI) Loop Output
1 x HDMI 2.0 Input
1 x HDMI 2.0 Output
Audio I/O1 x 1/4″ Headphone Output Network1 x RJ45, 10 Gb/s Media Slots2 x 2.5″ SSD
2 x SD Card
SSD Interface2 x 2.5″ SATA III 6 Gb/s Reference Input1 x BNC Reference Output1 x BNC Timecode1 x XLR (Input)
1 x XLR (Output)
16 x Channels SDI
8 x Channels HDMIOutput:
8 x Channels SDI
8 x Channels HDMI
SpeakerMono Device Control1 x RS-422 Input
1 x RS-422 Output
Supported Operating SystemsmacOS 10.15 Catalina
macOS 11.1 Big Sur or Later
Windows 10, 64-Bit
SDI ComplianceSMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 424M, SMPTE 425M level A and B, SMPTE 2081-1, SMPTE 2081-10, SMPTE 2084, and SMPTE 2108-1 SDI Metadata SupportHD RP188 and closed captioning CEA-708
HDR Metadata Supported on SDI
SamplingVideo: 4:2:2 YUV
Audio: 24-Bit, 48 kHz
Color Precision10-Bit Color SpaceRec. 601, Rec. 709, Rec. 2020
3D LUTS can be Applied to SDI Monitor Out
Multiple Rate SupportAutodetection of SD, HD, 6G-SDI, and 12G-SDI HDR SupportHybrid Log Gamma, ST2084 300, ST2084 500, ST2084 800, ST2084 1000, ST2084 2000, ST2084 4000, ST2084 Codecs SupportedProRes HQ QuickTime
ProRes 422 QuickTime
ProRes LT QuickTime
ProRes Proxy QuickTime for all Formats up to 2160p30
ProRes 4444 QuickTime up to 1080p60 with Auto Routing of Fill and Key over SDI A and B Outputs (Playback Only)DNxHD 220x, DNxHD 220x MXF, DNxHD 145, DNxHD 145 MXF, DNxHD 45, DNxHD 45 MXF for 720p and 1080p HD Formats up to 60 fps
DNxHR HQX, DNxHR HQX MXF, DNxHR SQ, DNxHR SQ MXF, DNxHR LB, DNxHR LB MXF for 2K DCI and 2160p Formats up to 30 fpsH.265 SDI 4:2:2 10-Bit, H.265 High 4:2:0 10-Bit, H.265 Medium 4:2:0 10-Bit, H.265 Low 4:2:0 10-Bit for all 2160p Formats up to 60 fps
H.264 SDI 4:2:2 10-Bit, H.264 High 4:2:0 8-Bit, H.264 Medium 4:2:0 8-Bit, H.264 Low 4:2:0 8-Bit for all Progressive formats up to 1080p60
Rack Size1 RUPower Power SourceAC Input AC Input Power100 to 240 VAC, 50 / 60 Hz DC Input Power12 VDC Power Consumption100 W (Maximum) Power Input Connection4-Pin XLR Input Operating Temperature32 to 104°F / 0 to 40°C Operating Humidity0 to 90% (Non-Condensing) Storage Temperature-4 to 140°F / -20 to 60°C Storage Humidity0 to 90%Physical Dimensions19 x 9.3 x 1.7″ / 48.3 x 23.6 x 4.4 cm Weight4.65 lb / 2.11 kgPackaging Info Package Weight7.17 lb Box Dimensions (LxWxH)21 x 10.5 x 3.6″
12 Month Limited Manufacturer’s Warranty
