Blackmagic Design Mini Converter – Audio to SDI 2
Embed audio into any SDI source in SD and HD formats up to 1080p60! Audio is input as balanced analog or AES/EBU using ¼ inch connectors from equipment such as mixers and analog decks. Mini Converter Audio to SDI is the ideal SD/HD SDI audio embedder for when you don’t need the cost of the Ultra HD model!
- Embed Audio into up to 1080p SDI Signals
- Four 1/4″ Audio Input Jacks
- Supports 4 Channels of Analog Audio
- Supports 8 Channels of AES/EBU Audio
- Redundant SDI Backup Input
Blackmagic Design CONVMCAUDS Specs
SDI Input1 x SDI on BNC (switchable between 3G/HD/SD)
1 x 3G/HD/SD-SDI redundant input (automatically switches over if main SDI input is lost)
Audio Input4 x 1/4″ jacks support 4 channels of balanced analog, or 8 channels of balanced AES/EBU digital audio SDI Output1 x SDI on BNC (switchable between 3G/HD/SD) SDI Auto SwitchingAuto-detection of 3G/2K/HD/SD-SDI Updates and ConfigurationVia USB 2.0 high-speed (480 Mb/s) ReclockingYes SDI ComplianceSMPTE 292M/259M/296M/372M/424M-B/425M
SDI Video RatesSDI video connections are switchable between HD and SD SDI Video Sampling4:2:2, 4:4:4 SDI Audio SamplingTelevision standard sample rate of 48 kHz and 24-bit SDI Color Precision4:2:2, 4:4:4 SDI Color SpaceYUV, RGB SDI Auto SwitchingAutomatically selects between 3G/HD/SD SDI Format Support1080p: 60/59.94/50/30/29.97/25/24/23.98
525i: 59.94 NTSC
625i: 50 PAL
2K Format Support2K DCI 25p/24p/23.98p
2K DCI 25PsF/24PsF/23.98PsF
Software ControlMac OS X and Windows software upgrade via USB Internal Software UpgradeVia included updater application Operating SystemMac OS X 10.11 El Capitan, macOS Sierra or later
Windows 8.1 or Windows 10
Settings ControlMini switches or USB software Power Supply+12 V universal power supply included, with international socket adapters for all countries and cable tie point Power Consumption8.4 W Operational Voltage Range12 VDC Operating Temperature32 to 104°F / 0 to 40°C Storage Temperature-4 to 113°F / -20 to 45°C Relative Humidity0 to 90% non-condensing Dimensions4.5 x 3.6 x 0.9″ / 11.5 x 9.2 x 2.3 cm Weight7.6 oz / 215 gPackaging Info Package Weight1.065 lb Box Dimensions (LxWxH)5.8 x 5.55 x 2.6″
3 Year Limited Manufacturer’s Warranty
