Blackmagic Design UltraStudio 4K Mini

UltraStudio 4K Mini is a portable Thunderbolt 3 capture and playback solution packed with the latest broadcast technology! You get broadcast quality 8 and 10‑bit high dynamic range capture in all formats up to 4K DCI at 60p, and 12‑bit high dynamic range capture in all formats up to 4K DCI at 30p. Plus, the built in SD card reader lets you mount camera media directly on your computer so you can start editing immediately!

RM5,969

Where to Buy
  • Features
  • Specs
  • Packing List
  • Warranty
    • 12G-SDI & HDMI 2.0 Input/Output
    • 1 x 40 Gb/s Thunderbolt 3 Interface
    • 3″ LCD Status/Preview Screen
    • DCI 4K60 4:2:2 Single-Link 12G-SDI I/O
    • DCI 4K30 4:4:4 Single-Link 12G-SDI I/O
    • DCI4K60 4:4:4 via HDMI
    • 8-, 10- & 12-Bit Processing
    • 2K/HD/SD via SDI or HDMI
    • RS-422 Deck Control
    • macOS, Windows & Linux Compatible
  • System Connection
    USB-C (Thunderbolt 3)
    Video Inputs
    1 x BNC (12G-SDI)
    1 x HDMI (HDMI 2.0b)
    2 x Coax (Component)
    Audio Inputs
    1 x XLR 3-Pin
    1 x 2RCA Stereo
    Video Outputs
    2 x BNC (12G-SDI) (Program)
    1 x BNC (12G-SDI) (Loop Output)
    1 x HDMI (HDMI 2.0b)
    2 x Coax (Component)
    Audio Outputs
    1 x 2RCA Stereo Female
    1 x 1/4″ TRS Female
    Other I/O
    1 x USB-C
    1 x DE-9/DB-9 Control
    Input Video Format
    SDI (10-Bit 4:4:4/4:2:2 YUV)
    DCI 4K up to 60 fps
    SDI (12-Bit 4:4:4/4:2:2 YUV)
    DCI 4K up to 30 fps
    UHD 4K up to 60 fps
    DCI 2K up to 60 fps
    DCI 2KPsF up to 30 fps
    1080p up to 60 fps
    1080i up to 60 fps
    720p up to 60 fps
    480i / 525 lines at 59.94 fps
    576i / 625 lines at 50 fps
    HDMI (8/10/12-Bit 4:4:4/4:2:2/4:2:0)
    DCI 4K up to 60 fps
    UHD 4K up to 60 fps
    1080p up to 60 fps
    1080i up to 60 fps
    720p up to 60 fps
    480i / 525 lines at 59.94 fps
    576i / 625 lines at 50 fps
    Input Audio Format
    Analog: 48 kHz
    Output Video Format
    SDI (10-Bit 4:4:4/4:2:2)
    DCI 4K up to 60 fps
    SDI (12-Bit 4:4:4/4:2:2)
    DCI 4K up to 30 fps
    UHD 4K up to 60 fps
    DCI 2K up to 60 fps
    DCI 2KPsF up to 30 fps
    1080p up to 60 fps
    1080i up to 60 fps
    720p up to 60 fps
    480i / 525 lines at 59.94 fps
    576i / 625 lines at 50 fps
    HDMI (8/10/12-Bit 4:4:4/4:2:2/4:2:0)
    DCI 4K up to 60 fps
    UHD 4K up to 60 fps
    1080p up to 60 fps
    1080i up to 60 fps
    720p up to 60 fps
    480i / 525 lines at 59.94 fps
    576i / 625 lines at 50 fps
    Output Audio Format
    Analog: 48 kHz
    Embedded Audio
    SDI: 16-Channel
    HDMI: 8-Channel
    Standards
    Video Standard Compliance
    SMPTE 259M/274M/296M/424M/425M-A/425M-B/2048-1/ST-2036/ST-2081-10/ST-2082-10/ST-2108-1
    HDR Compatibility
    HDR10, Hybrid Log Gamma
    Hardware
    Media Card Reader
    1 x SD (Unspecified Type) (UHS-II [312 MB/s])
    OS Compatibility
    macOS 11.1 to 12.0 or Later
    Windows 10 to 11 (64-Bit Only)
    Linux
    *As of December, 2022: Check with manufacturer for the most up-to-date compatibility
    Power I/O
    1 x USB-C Output
    1 x Barrel Input
    Power Consumption
    Power Supply: 100 to 240 VAC (75.3 W)
    Environmental
    Operating Temperature
    41 to 104°F / 5 to 40°C
    Storage Temperature
    -4 to 113°F / -20 to 45°C
    Operating Humidity
    0 to 90% (Non-Condensing)
    General
    Certifications
    FCC, ICES
    Dimensions
    7 x 1.8″ / 17.8 x 4.6 cm
    Weight
    2.65 lb / 1.2 kg
    Packaging Info
    Package Weight
    3.275 lb
    Box Dimensions (LxWxH)
    11.2 x 8.6 x 3.5″
  • 3 Year Limited Manufacturer’s Warranty
